當前位置:首頁>技術文獻電動扭剪扳手的使用方法及日常維護

電動扭剪扳手的使用方法及日常維護

來源:http://csbdjy.com日期:2024-02-13 發布人:創始人

為避免使用電動扭剪扳手時發生火災、觸電、人身傷害、機械傷害等事故,使用電動剪切鉗時須嚴格遵守以下規定。

To avoid accidents such as fire, electric shock, personal injury, and mechanical injury when using electric shear wrenches, the following safety regulations must be strictly followed when using electric shear pliers.

1.電源電壓不得超過電動扳手銘牌上額定電壓的10%。

1. The power supply voltage shall not exceed 10% of the rated voltage on the nameplate of the electric wrench.

2.扳手使用的電源插座須與扳手上的電源插頭匹配,輸入側的電源(電纜托架)須配備漏電保護器。

2. The power socket used for the wrench must match the power plug on the wrench, and the power supply (cable tray) on the input side must be equipped with a leakage protector.


3.電動扭剪扳手的本體、電線和漏電保護器須完好無損。

3. The body, wires, and leakage protector of the electric torsion wrench must be intact and undamaged.

4.高空作業時,扳手須系上繩。

When working at heights, the wrench must be fastened with a safety rope.

5.不允許在潮濕或雨天使用,或在儲存易燃易爆氣體的地方使用。

5. It is not allowed to use it in damp or rainy days, or in places where flammable and explosive gases are stored.

6.使用時應正確選擇合適的套筒。

6. When using, the appropriate sleeve should be selected correctly.

7.按照要求穿戴工作服、帽和帶,以在操作過程中保持身體平衡。

7. Wear work clothes, safety helmets, and seat belts as required to maintain body balance during operation.

8.不要拉動扳手上的鋼絲,也不要通過拉動鋼絲來拉動插頭。

8. Do not pull the wire on the wrench, and do not pull the plug by pulling the wire.

9.使用后,及時拔掉電源插頭。

9. After use, promptly unplug the power plug.

電動扭剪扳手的正確操作方法:

The correct operation method for electric torsion wrench:

在調整剪切扳手或更換附件和備件之前,請切斷電源。拆卸或安裝內外套筒時,不要讓異物進入工具。,從工具中安裝的彈簧上推出外套筒上的兩個螺釘,外套筒和內套筒,按壓螺栓并拆下內套筒。拆卸過程中小心不要使內套筒掉落,也不要將內套筒彈簧、推齒桿和推齒桿彈簧從工具上拆下。固定內套筒,使螺栓朝上。然后將外套套放在內套上,并按下螺栓固定內套。將外套筒和內套筒插入工具,并交替順時針和逆時針旋轉內套筒,直到外套筒和工具之間沒有間隙。

Before adjusting the shear wrench or replacing accessories and spare parts, please cut off the power. When disassembling or installing the inner and outer sleeves, do not let foreign objects enter the tool. Firstly, push out the two screws on the outer sleeve, the outer sleeve, and the inner sleeve from the spring installed in the tool, press the bolts and remove the inner sleeve. Be careful not to let the inner sleeve fall off during the disassembly process, and do not remove the inner sleeve spring, push tooth rod, and push tooth rod spring from the tool. Secure the inner sleeve with the bolt facing upwards. Then place the outer sleeve on the inner sleeve and secure it with the bolts. Insert the outer sleeve and inner sleeve into the tool, and rotate the inner sleeve clockwise and counterclockwise alternately until there is no gap between the outer sleeve and the tool.
